Evans Machinery for Countertops
|
MODEL
0110
POST
FORMER
Descriptions:
The Evans machinery model 0110 Post Former produces counter tops of uniform quality each and every time. It forms most radius without time consuming adjustments.
• Electrical 220v 1 Ph 14.5 KW
• Motor 1/3 HP
• Amps 80
• Working Height 36"
• Controls Pneumatic Push Button
• Maximum Length 12'
• Air Requirement 100 PSI
• Heater Overhead Radiant Cove Heated Bar
• Foot Print
• 180" x 28"
• Weight Crated 1800 lbs
|
MODEL
0190
COVING
MACHINE
Descriptions:
The evans machinery model 0190 coving machine is for bending inside cove bends for back splashes. The 0190 is available with either a 1/8", 3/16", or 3/8" radius coving rod heater that is thermostatically controlled. Other options available include a timer and pneumatic bending clamps.
• Coving Length Maximum 12'
• Backsplash Height Minimum 1" Maximum 34"
• Air 80 PSI
• Electrical 110v 1 Ph 15 Amps or 220v 1 Ph 8 Amps
• Weight 1800 lbs. |
|
|
|
MODEL
0132
ALL
FORM
Descriptions:
The Evans Machinery model 0132 All Form is designed for 12 foot capacity. This new, exclusive forming machine is capable of wrapping 90º or 180º and beveled edges without set up changes.
• Electrical 220v 1 Ph 60Hz or 380V 3 Ph 50Hz
• Air Requirement 80 PSI
• Material Size 144" Long 3" Thick Unlimited width |
MODEL
6100
FORM-O-MATIC
Descriptions:
The Evans model 6100 Form-O-Matic is a double sided, single stage automatic postformer.
• Machine Length 107"
• Machine Width 72"
• Machine Height 44"
• Feed Motor 1/2 HP DC
• 90º Laminate floating Trimmers (Optional)3/4 HP Per Station
• Slitter saw motor (Optional) 2HP
• Heater Infrared Radiant Panel Heater
• Power Consumption (Minimum)13 KW
• Power Consumption (Maximum)17 KW
• Electrical 220 VAC 3 Phase 60 Hz
• Feed Speed Up to 10 FPM
• Material Length Minimum 48"
• Material Thickness Min. 0.63" Max. 1.75"
• Material Width Max 48.5" Min With Saw 16.5" Min. Without Saw 8"
• Build Down 90º or 180º
• Build Down Thickness 90º Max. 1.25" - 180º Max. 0.75"
• Build Down Depth 90º Max. 1.75" - 180º Max. 1.75" |
|
|
|
MODEL
0161
COVING
MACHINE
Descriptions:
The evans model 0161 automatic hot melt coving machine meets the demand for economical production of consistently accurate and strong postformed backsplashes.
• Machine Height 58"
• Machine Width 60"
• Machine Length 176"
• Working Height 37"
• Weight 2700 lbs.
• Electrical 42 Amps 220v 60 Hz 1Ph or 42 Amps 380v 50 Hz 3 Ph
• Air Supply 90 PSI
• Capacity Length Max. 145"
• Capacity Deck Depth 14.5" to 30"
• Capacity Backlash Height Min. 2.5"
• Capacity Coving Radius 3/16" or 1/8". |
MODEL
0366
INDEX
TABLES
Descriptions:
The evans machinery model 0366 Ezy-fit Index Table aligns laminate and core stock accurately.
• Air operated - 80 PSI
• 5' Wide x 12' Long x 30" High with Leg lever adjustment
• Steel frame construction
• Quick adjustments for any width material up to 60" wide
• Adjustable plastic index
• Airline pressure regulator
• Filter and lubricator cylinder operation
• Evans steel indexing pins
• Pneumatically operated adjustable gate locks allow forward positioning of core-board with laminate |
|
|
|
MODEL
0206
PINCH
ROLLER
Descriptions:
The evans machinery Inc. Model 0206 Pinch Roller is a key asset for laminating shops both large and small. The top toller is easily adjustable to the thickness of the work being laminated. Simply insert the provided spacers 1/8, 1/4, 1/2 and 3/4. Yuo can use any combination to aquire the desired thickness.
• Electrical 110v
• Drive Motor 1/2 Hp
• Amps 8
• Working Height 30-1/2"
• Maximum Thickness 2"
• Maximum Width 62'
• Air Requirement 100 PSI
• Feed Rate 50 FPM
• Foot Print
• 74" x 28"
• Weight Crated 800 lbs. |
MODEL
0710
MITER
SAW
Descriptions:
The evans model 0710 miter saw guarantees precision cut miters every time.
• Electrical 220v 3 Ph
• Motor 3 HP
• Feed Rate 1-50 FPM
• Air Requirement Minimum 80 PSI
• Amps at 220 Volt 10
• Working Height 35"
• Drive Double V Belt
• Maximum width of cut at 90º 39"
• Maximum width of cut at 45º 27"
• Maximum width of cut at 22-1/2º 36"
• Maximum Stroke of Cut 50"
• Foot Print 100"w x 85"d
• Spindle Diameter 1"
• 16" 100 Tooth Saw Blade Included |
|
|
|
MODEL
7300
DRAWBOLT
CUTTER
Descriptions:
The evans machiney model 7300 Draw Bolt Cutter is a simple, accurate, and safe to operate, and is designed to route your draw bolt cut-outs in less than one minute on either countertops or bar tops.
• Air Requirement 100 PSI
• Electrical 110v
• Foot Print 35" x 40"
• Number of Cut-Outs 4
• Working Height 35"
• Weight Crated 170 lbs. |
MODEL
5010
LAMINATE
/ VENEER SLITTER
Descriptions:
The evans machinery model 5010 slitter readily replaces existing straight shears, table saws or routing systems used for cutting high pressure laminate or wood veneer.
• Electrical 110v 1 Ph
• Motor 1/3 HP
• Amps 10
• Working Height Bench Top
• Maximum Cut 6"
• Air Requirement N/A
• Foot Print 37" x 24"
• Weight (Crated) 250 lbs. |
|
|
|
MODEL
5031
LAMINATE
/ VENEER SLITTER
Descriptions:
The evans machinery model 5031 slitter readily replaces existing straight shears, table saws or routing systems used for cutting high pressure laminate or wood veneer.
• Electrical 110v 1 Ph
• Motor 1/3 HP
• Amps 10
• Working Height 36"
• Maximum Cut 31"
• Air Requirement N/A
• Foot Print 70" x 50 "
• Weight (Crated) 925 lbs. |
MODEL
2480
OVERARM
ROUTER
Descriptions:
The evans machinery model 2480 overarm router is a compact heavy duty system for cutting sink holes in countertops of various materials.
• Electrical 220v 3 Ph
• Motor 3 HP
• Amps 10
• Working Height 33"
• Maximum Cut 30" Deep x 48" Wide
• Air Requirement 100 PSI
• Foot Print 65" x 70"
• Weight (Crated) 1200 lbs. |
|
|
|
MODEL
1050
T-EDGE
Descriptions:
The evans machiney model 1050 Ezy-T-Edge is perfect for the complete application of plastic T-molding, producing a smooth, even, contoured edge on tops, counter tops, door and drawer fronts, and a variety of work surfaces.
Miter Notching Index: Efficient operation with 3/16" tolerance on either side of miter notch. Eliminates buckling of T-molding when going around square or small radius corners.
Cut-Off Index: Automatic for precise cut-off, does not require accurate judgment by operator. Pneumatically operated by foot levers, keeping hands free to handle the work piece |
MODEL
4253
SEMI-AUTOMATIC
INDEX TABLE
Descriptions:
With over 40 years of proven reliability, the Evans machinery model 4253 index table is a great addition to any continuous laminating system. The 4253 provides for a single sheet of substrate to be laminated on both sides, and no one touches the glue line.
• Air Requirement 100 PSI
• Working Height In-Feed 43"
• Foot Print 177" x 87"
• Maximum Board Size 61" x 145"
• Working Height Out-Feed 40"
• Weight Crated 1200 lbs. |
|
|
|
MODEL
4604
HEAT
TUNNEL
Descriptions:
The evans machinery model 4604 Heat Tunnel provides an efficient, compact method of laminating high pressure laminate to a substrate using an environmentally safe, non flammable, water soluable PVA adhesive.
• Machine Length 52"
• Machine Width 80"
• Machine Height 58"
• Working Height 40"
• Weight 3,000 lbs.
• Electrical 220 or 440 Volt 3 Ph
• Drive Motors 3/4 Hp
• Air Supply 100 PSI
• Feed Rate 1-12 Feet Per Minute
• Max. Material Width 61"
• Min. Material Length 23"
• Max. Material Length 144" |
MODEL
6600
DOUBLE
END CORE SHAPER
Descriptions:
The Evans machinery model 6600 core builder produces a quality core every time.
• Machine Length 158"
• Machine Width 89"
• Machine Height 72"
• Working Height 36"
• Electrical 220v 60 Hz 3 Ph
• Air Supply 100 PSI
• Edge Shaper 5 HP 5850 RPM 1.25 Spindle Diameter
Hot Melt Unit
• 20 lbs Capacity 1500 Watt Heater
• Feed Rate 20 FPM
• Center Feed Drive Non-Skid Pad
• Board Width 16" Min. to 48" Max
• Board Thickness 2" Maximum
• Build Up Width 3/4" Min. to 1-1/2" Max.
• Build Up Thickness 1-1/2" Maximum
• T-Mold Slotter 1-1/2 HP 3600 RPM .875" Spindle diameter 8" Blade
• Groover 1-1/2 HP 3600 RPM .875" Spindle diameter 8" Blade |
|
|
